The TRICONEX 3625C1, developed by Invensys under the TRICONEX brand, is a 24VDC Digital Output Module of great significance in industrial control.
1. Electrical Specifications
It operates with a nominal voltage of 24VDC, which is a common and stable power source in many industrial setups. The maximum voltage it can handle is 36VDC. With a voltage drop of less than 2.8VDC at 1.7A (typical), it ensures efficient power delivery. Each of its 16 output channels has a current rating of 0.5A, enabling it to drive a variety of industrial devices such as solenoid valves, relays, and small - scale actuators.
The module supports the Modbus RTU communication protocol, which allows for seamless integration with other Modbus - compatible devices in the industrial network. This communication protocol enables reliable data transfer for controlling and monitoring the output status.
2. Operational Conditions
In terms of temperature, the 3625C1 can function within a wide operating temperature range from - 40 °C to 70 °C. This makes it suitable for use in diverse industrial environments, whether it's a cold storage facility or a high - temperature manufacturing plant. During storage, it can endure temperatures from - 40 °C to 85 °C.
It can tolerate humidity levels in the range of 5% to 95% non - condensing. This high humidity tolerance ensures that the module can operate reliably even in areas with high moisture content, without the risk of damage due to condensation.
3. Physical Attributes
With dimensions of 100 mm x 80 mm x 35 mm (3.9 in x 3.1 in x 1.4 in), it has a compact size that allows for easy installation in control panels and enclosures. This compact design also contributes to space - saving in industrial control cabinets.
4. Applications
The 3625C1 is widely used in safety - instrumented systems (SIS) across industries like oil and gas, chemical processing, and power generation. In these safety - critical applications, it plays a crucial role in sending out digital control signals. For example, in an oil refinery, it can be used to control the opening and closing of emergency shutdown valves in case of abnormal situations, ensuring the safety of the entire plant. It also finds applications in general industrial automation and process control systems, where it helps in accurately controlling the operation of various field devices, enhancing the overall efficiency and reliability of industrial processes.
TRICONEX 3625C1 24VDC Digital Output Module Invensys Schneider
TRICONEX 3625C1 24VDC Digital Output Module Invensys Schneider
TRICONEX 3625C1 24VDC Digital Output Module Invensys Schneider
TRICONEX 3625C1 24VDC Digital Output Module Invensys Schneider
