The FOXBORO FBM216 P0917TN is a pivotal module within the IA Series, designed for high - performance industrial control and monitoring applications. It is a 8 - channel module that specializes in communication and redundant HART input functions.

Redundant HART Input Capabilities

The FBM216 is engineered to support a mix of standard 4 - 20 mA devices and HART - enabled devices. Each of its eight group - isolated input channels can interface with various field sensors. The redundancy feature at the fieldbus module (FBM) level is a significant advantage. When paired with another FBM216, one module acts as the master and the other as the tracker. For every input operation, identical reads are transmitted to both modules. This not only fully utilizes the fieldbus and the logic circuitry of each module but also enhances the reliability of the input data acquisition. The redundant power supply for the input current loop, sourced from per - channel power supplies in each module of the pair, further boosts the security of the input channels.

Communication Functionality

As a HART communications field device host, the FBM216 enables seamless interaction between the IA Series system and field devices. It can request and receive two digital messages per second from each connected field device. This allows for the implementation of HART universal, common practice, and device - specific commands (excluding the burst communication mode) using the intelligent field device configurator (IFDC). The module provides a common isolated power supply for all eight channels. However, in cases where an external power supply is preferred for the channels, a cable balun module can be incorporated to prevent channel crosstalk.

Technical Specifications and Design Features

Internally, the FBM216 uses a sigma - delta converter, which is capable of providing new analog input values for each channel every 100 milliseconds, ensuring high - accuracy data conversion. Its compact design, with a rugged extruded aluminum exterior, offers physical protection to the internal circuits. The module can be installed in enclosures that provide different levels of environmental protection, suitable for harsh environments as per ISA standard S71.04. On the front of the module, light - emitting diodes (LEDs) are integrated. These LEDs serve as visual indicators, showing the module's operational status, redundancy status, and communication activity on the channels. Additionally, two more LEDs clearly display the master or tracker status of the modules.

In summary, the FOXBORO FBM216 P0917TN is a reliable and feature - rich module. Its ability to handle redundant HART inputs, efficient communication capabilities, high - accuracy data conversion, and robust design make it an ideal choice for industrial applications where reliable data acquisition and communication between the control system and field devices are crucial.
