The GE Fanuc VMIC VMIVME - 7486 is a high - performance PC AT VMEbus CPU single - board computer (SBC) designed for industrial control and automation applications5. Here is a detailed introduction:

Hardware Features

Processor and Memory1: It has a high - performance CPU with a 66 - MHz clock speed, and is equipped with a coprocessor. It also comes with an 8 - kilobyte four - way set - associative cache - on - chip, which can speed up data access and processing. In terms of memory, it supports up to 16 MB of DRAM, and has 1 MB of video DRAM onboard, which, combined with the super VGA (1024 x 768 non - interlaced resolution), can provide a good display effect.

Interface1: The board is equipped with a parallel centronics port, two serial RS - 232C ports, a PC / AT keyboard interface, and a real - time clock with an onboard battery. In addition, it also integrates floppy and IDE controllers, which can be easily connected to external storage devices.

Bus and Communication5: It adopts a VMEbus interface, which has the advantages of high - speed data transmission and good expandability, and can be seamlessly integrated with other VMEbus - compatible devices.

Technical Characteristics

Compatibility1: It is 100% PC / AT - compatible, which means it can run common PC - based operating systems and software, such as DOS and Windows, facilitating users to use familiar development and operation environments.

Custom Gate Array Technology1: The use of custom gate array technology provides full VMEbus functionality, including an interrupt handler module, an interrupter, and a system controller. This allows the module to access all VMEbus memory in both real and protected modes, and is equipped with three - way byte - swapping hardware for little - endian and big - endian type interfacing, enhancing the flexibility and adaptability of the system.

Working Environment

Temperature Range5: It has a wide operating temperature range of - 40 °C to + 85 °C and a storage temperature range of - 40 °C to + 85 °C, which can adapt to various harsh industrial environments.

Application Areas

Industrial Automation: It can be used in factory automation production lines to control and monitor various devices such as motors, sensors, and actuators to achieve automated production processes.

Process Control: In the process control of the chemical, petroleum, and other industries, it is used to collect and process data from various process parameters such as temperature, pressure, and flow, and realize the monitoring and control of the production process.

Test and Measurement: It can be applied to the test and measurement system, combined with the test equipment to complete the data acquisition, analysis, and control functions, and improve the accuracy and efficiency of the test.
