Bently 135031-01 Rack interface I/O module

Bently 135031-01 Rack interface I/O module

1.Warranty time: 1 year

2.Delivery time: 3-5 days

3.Product quality: new or discontinued second-hand

Inquire Now

Tags:

Additional Information:

1. We are a global trading company, we have a large stock of spare parts, we also produce energy storage batteries

2. Our main sales products are industrial automation control equipment accessories, such as: controller board, processor module, communication module, input and output module, power module (various circuit boards and cards), touch screen, servo driver, servo motor, sensor, cable......

3. We can not only provide new products, but also supply cold and discontinued spare parts, all the discontinued parts will go through strict testing to ensure the reliability of product performance, so that customers can buy and use at ease

4. For more information, please contact us: Contact: Amy | Email: saul01@qq.com | Tel(WhatsApp/Wechat): +86-15359298283

Full Chinese details of Bently Nevada 135031-01, combined with its central role in mechanical protection systems:

Core identity

Bently Nevada 135031-01 is the key Power Distribution Module of the 3500 Series mechanical protection system, designed to provide redundant DC power supply and backboard communication management for the in-rack monitoring module. It is the "heart" component to ensure the reliable operation of the whole system.

Key functions and technical features

The central role

Dual power input: support 24VDC master/standby power seamless switching to ensure uninterrupted system operation.

Power distribution: Power supply to 12-slot monitoring modules (such as vibration probe, displacement monitor) through the backplane.

Communication hub: manages the RS-485 data bus of the in-rack module and coordinates data transmission to the upper system.

Electrical specifications

Parameter specification

Input voltage 18-30VDC (dual independent input)

Total output power 120W (fully equipped with 12 modules)

Power switching time ≤5ms (zero interrupt switching)

Isolation protection input reverse/overvoltage/short circuit protection

Module identity resolution

135031: Basic model (Power Distribution module)

-01: Hardware version (original standard version)

Physical Characteristics:

Width: double Slot (Slot 1-2)

Status light: Power supply 1/ power supply 2 running status (green), fault (red)
