ABB 500CPU03 (part number: 1HDF700003R5122) belongs to the core processor module of the **AC500 series programmable logic controller (PLC), designed for industrial automation scenarios, supporting complex control logic and real-time data processing, suitable for manufacturing, energy, water treatment and other fields.

Core Features

High performance processing capability

Equipped with an optimized processor, it supports fast logic operation and multi-task processing to meet the requirements of high-speed control.

Program memory capacity supports flexible expansion, can adapt to different sizes of application scenarios (such as AC500 V3 series memory up to 8MB).

Rich communication interface

Integrated Ethernet interface (support Modbus TCP, UDP/IP and other protocols), can be directly connected to the host computer or cloud platform, to achieve remote monitoring and data interaction.

Built-in dual RS232/485 serial port (COM1/COM2), support Modbus RTU, ASCII protocol and CS31 bus, suitable for distributed I/O extension and device communication.

Support CANopen main interface, J1939 and other industrial protocols, can be connected to the fieldbus adapter to achieve multi-device cooperative control.

Modularity and extensibility

Support local I/O extension (up to 10 modules) and distributed I/O architecture (through FBP interface or CS31 bus), compatible with AC500 series standard modules (such as digital and analog modules).

Extendable storage via SD card for program backup, firmware upgrade and data logging.

Industrial grade reliability

Fanless design, suitable for wide temperature environment (-25°C to + 60°C), protection level up to IP20 (can be installed in the control cabinet).

Built-in fault diagnosis function, through the LCD display real-time error code (such as E3 008 prompts slight error), support quick location and repair.

Digitalization and IOT support

Onboard HTML5 web server, you can directly access the device status and parameters through the browser, without additional software.

Compatible with ABB Ability™ Automation Builder engineering suite, support IEC 61131-3 standard programming languages (such as structured text, ladder diagram), simplify the development process.

Typical Applications

Industrial production line: realize equipment linkage, process parameter adjustment and production data traceability.

Energy management: monitoring power systems, optimizing energy distribution and failure warning.

Water treatment: control pump valve start and stop, water quality monitoring and automatic dosing system.

Process control: It is suitable for continuous production process of food and beverage, chemical and other industries.

Technical parameters (refer to AC500 series)

Project Specification Description

Processor type 32-bit RISC architecture, frequency ≥100MHz (specific model depends on the version)

Program memory 512KB to 8MB (depending on the model, such as PM566 support 512KB, AC500 V3 up to 8MB)

Data memory 100KB to 2MB, support power-down maintenance (no battery required)

Communication interface Ethernet ×1, RS232/485×2, CANopen×1, FBP interface ×1

I/O expansion capability Local 10 modules, distributed up to 31 slaves (CS31 bus)

Power supply voltage 24V DC (±15%), power consumption ≤10W

Operating temperature -25°C to + 60°C (no condensation)

Certification CE, UL, ATEX (some models)

Installation and Configuration

Installation of hardware

It needs to be used with AC500 series baseplate (such as TB511-ETH) and power module (such as PS501) to support DIN rail or panel installation.

Communication modules, such as CM577-ETH, can be extended with additional interfaces and need to be configured through SYCON.net software.

Software configuration

Use ABB PS501 or Automation Builder software for programming and debugging, support online monitoring, variable tracking and firmware upgrade.

The IP address, communication parameters and user permissions can be directly configured through the Web server to simplify the initial setup process.
