ABB UFC760BE145 3BHE004573R0145 module Chinese details

Product Overview

UFC760BE145 3BHE004573R0145 is a frequency converter control module launched by ABB, which belongs to the core component of the ACS800 series industrial drive system. Designed for motor speed regulation and energy saving control, this module supports precise torque, speed and position control, and is widely used in industrial production lines, fan, pump equipment and drive systems for heavy machinery.

Technical parameters

Description of property

Model UFC760BE145 3BHE004573R0145

Applicable drive ABB ACS800 series inverter

Input voltage 380-480 V AC (three-phase, ±10%)

Output power range 0.55 kW to 160 kW (depending on the supporting module)

Control mode: vector control (DTC), V/f control

The communication interface supports PROFIBUS DP, Modbus RTU, CANopen, etc

Operating temperature -15°C to +50°C (without volume drop)

Protection grade IP20 (must be installed in the control cabinet)

Certification standard CE, UL, cUL, ISO 13849 (Functional safety standard)

Core Functions

High performance motor control

Direct torque control (DTC) technology is used to achieve fast dynamic response and high-precision speed regulation (±0.1% speed accuracy).

Support asynchronous motor and permanent magnet synchronous motor (PMSM) drive.

Energy saving and optimized operation

Built-in energy optimization algorithm, automatically adjust output power according to load, reduce energy consumption.

It is suitable for variable load scenarios such as fans and water pumps, and the energy saving effect is significant (up to 50%).

Safety and protection

Integrated over current, over voltage, over heat, short circuit and other protection functions, in line with SIL2/SIL3 safety level requirements.

Support safe torque off (STO) function to ensure emergency shutdown safety.

Flexible communication and integration

A variety of communication modules (such as EtherNet/IP, PROFINET) can be added through the expansion card slot.

Compatible with ABB 800xA system, supporting centralized monitoring and remote maintenance.

Application scenarios

Manufacturing: production line conveyor belt speed control, injection molding machine motor control.

Energy and utilities: fan speed control, pump flow control (such as sewage treatment plants).

Mine and metallurgy: hoist, mill drive system.

Building automation: air conditioning system, elevator drive control.

Installation and Configuration

Hardware installation: Modular design, directly into the ACS800 inverter unit, support DIN rail or wall mount installation.

Parameter Settings: Control parameters and communication protocols were configured by ABB DriveWindow or PC Tool software.

Debugging support: built-in self-tuning function, can automatically match the motor parameters, simplify the debugging process.

Advantages and characteristics

Compact and efficient: high power density design, saving control cabinet space.

Multi-protocol compatibility: seamless integration into Industrial Internet of Things (IIoT) and SCADA systems.

Long life design: using industrial grade components, MTBF (mean time to failure) more than 100,000 hours.

Points to note

Heat dissipation requirements: ensure that the installation environment is ventilated to avoid high temperature resulting in performance reduction.

Emc: Use shielded cables and follow ABB wiring specifications to reduce electromagnetic interference.

Firmware UPDATE: REGULARLY CHECK ABB's OFFICIAL website to update firmware to support new features or fix bugs.
